Overview
Advanced nnU-Net architecture for automated brain tumor segmentation in MRI scans, achieving state-of-the-art performance on the BraTS dataset with Dice scores >0.9 across all tumor regions.
The Problem
Manual brain tumor segmentation by radiologists is time-consuming (30-60 minutes per scan), subjective, and prone to inter-observer variability. Accurate delineation of tumor boundaries is critical for treatment planning, but tumor heterogeneity and unclear boundaries make automated segmentation challenging.
The Solution
Implemented and optimized the nnU-Net framework specifically for 3D medical imaging. The system automatically configures network architecture, preprocessing, and training strategies based on dataset properties. Custom loss functions combine Dice and cross-entropy to handle class imbalance, while extensive data augmentation improves generalization.
Project Gallery
Technical Architecture
Self-configuring 3D U-Net with automated hyperparameter optimization
3D U-Net Encoder
Five-level encoder with residual connections extracting hierarchical features from 3D MRI volumes
Decoder with Deep Supervision
Symmetric decoder with skip connections and auxiliary loss heads at multiple resolutions
Automated Configuration
Dataset fingerprinting automatically determines patch size, batch size, and network topology
Ensemble Prediction
Combines predictions from 5-fold cross-validation for robust segmentation
Methodology
- Dataset: BraTS 2020 (369 training cases, 125 validation cases)
- Preprocessing: N4 bias correction, intensity normalization, resampling to 1mm isotropic
- Training: 5-fold cross-validation, 1000 epochs per fold, mixed precision training
- Augmentation: Random rotations, scaling, elastic deformations, Gaussian noise
- Post-processing: Connected component analysis, morphological operations
- Evaluation: Dice score, Hausdorff distance (95th percentile)
Results & Impact
Key Impact
- Achieved state-of-the-art performance on BraTS leaderboard
- Reduced segmentation time from 45 minutes to 8 seconds (95% reduction)
- Deployed in clinical workflow at partner hospital
- Enabled high-throughput analysis for research studies
- Improved treatment planning accuracy
Challenges & Solutions
GPU Memory Constraints
Implemented patch-based training with sliding window inference for full-resolution predictions
Class Imbalance
Combined Dice + Cross-Entropy loss with online hard example mining
Tumor Heterogeneity
Extensive augmentation and multi-scale feature fusion
Key Implementation
3D U-Net Architecture
class UNet3D(nn.Module):
def __init__(self, in_channels=4, num_classes=4):
super().__init__()
# Encoder
self.enc1 = self.conv_block(in_channels, 32)
self.enc2 = self.conv_block(32, 64)
self.enc3 = self.conv_block(64, 128)
self.enc4 = self.conv_block(128, 256)
# Bottleneck
self.bottleneck = self.conv_block(256, 512)
# Decoder with skip connections
self.dec4 = self.upconv_block(512, 256)
self.dec3 = self.upconv_block(256, 128)
self.dec2 = self.upconv_block(128, 64)
self.dec1 = self.upconv_block(64, 32)
# Output
self.out = nn.Conv3d(32, num_classes, kernel_size=1)
def forward(self, x):
# Encoder
e1 = self.enc1(x)
e2 = self.enc2(F.max_pool3d(e1, 2))
e3 = self.enc3(F.max_pool3d(e2, 2))
e4 = self.enc4(F.max_pool3d(e3, 2))
# Bottleneck
b = self.bottleneck(F.max_pool3d(e4, 2))
# Decoder
d4 = self.dec4(b, e4)
d3 = self.dec3(d4, e3)
d2 = self.dec2(d3, e2)
d1 = self.dec1(d2, e1)
return self.out(d1)
